Pacer Pumps’ S Series Self-Priming Centrifugal pumps are lightweight, chemically resistant pumps for general service on water, salt water, waste water, mild acids and bases. They feature non-metallic solution contact or stainless steel internal fasteners; Viton®, ethylene propylene or Buna O-rings and gasket with stainless steel external fasteners. The pumps are molded of tough, glass-reinforced polyester, polypropylene or Ryton®. Polyester models are available with or without lined volute for abrasion resistance. Cast iron pedestal and solid 316 stainless steel shaft.

All pumps include a built-in check valve, feature easy servicing and during pumping, a self-cleaning double volute keeps pump free of settled solids.

Features:

Choice of materials: pump constructed of: polyester, polypropylene or Ryton®. Suitable elastomers, and stainless steel or non-metallic fasteners for resistance to chemical attack
Choice of drives: electric motor, gasoline driven, hydraulic or pneumatic driven
Close-coupled, long-coupled or pedestal mounted
Built-in check valve
Flow rates: to 280 U.S. GPM or 120 ft. TDH @ 60 Hz (to 883 LPM or 25.4m TDH @ 50 Hz)
Suction lift to 25 ft. (7.6m) vertical
1 1/2″, 2″ or 3″ ports, NPT, BSP available in polyester only

Curve	Port Size	Req’d HP	RPM	Weight	Model
A	1 1/2″	1/2	1750	24#	SE1-1/2AL CSS
C	2″	1	1750	24#	SE2CL CSS
E	2″	2	3450	24#	SE2EL CSS
F	2″	5	3450	24#	SE2FL CSS
H	2″	3	3450	24#	SE2HL CSS
I	2″	7.5	3450	24#	SE2IL CSS
J	2″	5	3450	24#	SE2JL CSS
L	3″	5	3450	24#	SE3LL CSS
